Home » Products » Industrial Food Dryer » Soup Freeze Dryer Machine

Soup Freeze Dryer Machine

Soup Freeze Dryer Machine
Soup Freeze Dryer Machine
Product Code : 17
Product Description

We have been setting benchmarks of success in the market as a prominent manufacturer and supplier of Soup Freeze Dryer Machine. This machine is better for liquid material like soup and paste, mainly for small or medium production in food industry. Our diligent workforce uses quality grade material to manufacture this machine. The machine can dry fresh food material without nutrition lost, and meanwhile preserves its original taste, flavor and color. Easy to operate and install, this Soup Freeze Dryer Machine comes in different technical specifications for clients.

Features:

  • Longer service life
  • Robust construction
  • Maintenance free


Soup Freeze Dryer Machine

Technical parameters of Soup Freeze Dryer Machine :

Model

FD10

FD20

FD30

FD50

FD100

FD200

FD300

FD500

FD1000

Capacity (kg/batch)

10

20

30

50

100

200

300

500

1000

Trays area (m2)

1

2

3

5

10

20

30

50

100

Chamber size (Φ*L)

0.7*0.7

0.8*0.9

0.9*1.0

1.0*1.2

1.2*1.5

1.4*1.9

1.5*2.3

1.8*2.5

2.5*5.5

Plate temperature (°C)

-50-60

-50-60

-50-60

-50-60

-50-60

-50-60

-50-60

0-110

0-110

Condenser temperature(°C)

-60

-60

-60

-60

-60

-60

-60

-60

-60

Vacuum level (Pa)

3

3

3

3

3

3

5

10

15

Plates size (cm)

40*55

70*50

63*95

102*70

119*80

170*100

190×60

232*120

500*60

Plates layers

5+1

5+1

7+1

7+1

8+1

8+1

13+1

17+1

17+1

Plates distance (mm)

80

75

75

75

70

70

70

70

70

Cooling water (≤25°C) recyclable

2t/h

3t/h

5t/h

5t/h

8t/h

15t/h

25t/h

40t/h

100t/h

Defrost

By water or 60°C hot water

Use environment

Temperature 5°C~30°C/41°F~86°F, Humidity <75%

Total power (kw)

12

16

18

22

40

60

90

150

230

Power consumption

8kwh

10kwh

11kwh

14kwh

24kwh

36kwh

54kwh

90kwh

138kwh

Install area (m2*H)

8*2.5

15*2.5

20*2.5

25*2.5

35*2.5

45*2.5

50*2.5

100*3

200*3.5

Weight

1.8t

2t

2.3t

2.5t

6.5t

8.5t

9t

10t

22t
