30kg Batch Freeze Dryer

30kg Batch Freeze Dryer
30kg Batch Freeze Dryer
Product Code : 03
Product Description

We have been able to attain strong market goodwill as a trusted organization engaged in manufacturing and supplying 30kg Batch Freeze Dryer. Freeze drying is a slow batch process used in pharmaceutical & biochemical industries to extract dry product from an aqueous solution. To manufacture this 30kg Batch Freeze Dryer we use optimum quality materials and components. The product is usually is placed on shelves in a vacuum chamber, which is first frozen and then evacuated. We offer this dryer at market leading prices to clients.

Features:

  • Robust construction
  • Consumes low power
  • Easy to operate



30kg Batch Freeze Dryer

Technical parameters of freeze dryer:

Model

FD-30

Type

Conductive, all in one

Ice Capacity (kg)

30kg in a 24hr period (vapor condenser capacity)

Vapor Condenser Temperature (℃)

-45℃ (option: -60℃)

Usable Shelf Area (m2)

3 m2

Number of Shelves

7+1, the top plate provides radiant heat only

Shelf Dimension (mm)

725*600mm (thickness: 15mm) SUS304

Shelf Spacing (mm)

40-80mm

Shelf Temperature (℃)

-25℃ to 70℃ (option: -45℃ to 70℃)

Shelf Cooling Rate (+40℃ to –25℃)

≤ 60 minutes

Shelf Heating Rate (℃/min) (approx.)

1℃/min, By electricity

Heating/cooling medium

Silicone oil

Heating/cooling exchange

By plate type of heat exchanger

Number of Product Trays

7 pieces

Tray Dimension (mm)

720*595mm (height: 25mm) SUS304

Ultimate vacuum level (Pa)

5 Pa

Chamber vacuum rate (atm to 100 Pa)

≤ 15 minutes

Refrigeration

Standard Xueying/Xuemei, Brand option: Bitzer.

Refrigerant

R404A/R507

Cooling way

By water cooling or air cooling as option

Cooling water flow rate

4-5t/hr,<28℃

Vacuum system

Standard Yoivac, Option: Ulvac/Leybold/Edwards

Energy consumption (24hr)

5.09kWh/kg by water cooling

Power requirement

7.95kw, 110-240V single, 240-480V, 3P, 50/60Hz

Defrost way

By water or 60°C hot water

Control system

PLC with HMI

Installation area (m2)

20 m2

Chamber – over all dimension

2486*1100*2000mm (L*W*H), SUS304

Weight (kg)

2000kg
